ModelMD 4C NT +AK SYNCHRO+EK
Voltage100 to 115/120 V
Amperage4 A
IncludesManual
MaterialFluoropolymer, PTFE (Pump Head)
Oil TypeOil-Free
Flow Rate2/2.2 CFM
Frequency50/60 Hz
Plug TypeUS
Pump TypeDiaphragm Pump
Horsepower0.34 hp
Max. Vacuum1.1 torr (without Gas Ballast), 2.3 torr (with Gas Ballast)
Motor Speed150 to 1800 rpm
Noise Level45 dB(A)
ApplicationsVacuum Drying Ovens
For Use WithProvides the simultaneous operation of two processes with only one pump
No. of Stages3
Enclosure RatingIP40
Maximum Pressure1.1 bar
No. of Pump Heads4
Resistance PropertiesChemical-Resistant
Overall Width (Metric)248.92 mm
Electrical Requirements120 V 60 Hz
Overall Height (Metric)401.32 mm
Overall Length (Metric)325.12 mm
Overall Width (English)9.7 in.
Overall Height (English)15.8 in.
Overall Length (English)12.8 in.
Temperature (Metric) Max40°C
Certifications/ComplianceCE, DIN EN 1012-2:2011, DIN EN 12100:2001, DIN EN 50581:2013, DIN EN 61010-1:2011, DIN EN 61326-1:2013, IEC 61010-1:2010, NRTL Certification, TUV
Temperature (English) Min50°F
Temperature (Metric) Min.10°C
Temperature (English) Max.104°F
Temperature (Metric) Storage-10°C to +60°C
