TypepH/mV Meter
ModelAB315
InputsBNC, ATC
MemoryNon-volatile
OutputsPort for Computer or Printer
Voltage100/240 V
Channels1
IncludesElectrode Stand, Power Adapter
Warranty3 Years
Frequency50/60 Hz
IP RatingIP54
StabilityIndicator Icons
AC AdapterUniversal Power Adapter
Range (m V)±2000 mV
Range (p H)-2 to 18
CalibrationpH, Relative mV, Temperature
Data Points500
DescriptionpH/mV Meter with Electrode Stand
Display Type5 in. LCD
Accuracy (m V)±0.2 or ±0.05%, Whichever is Greater
Accuracy (p H)±0.01
Resolution (m V)1 mV, 0.1 RmV
Resolution (p H)0.01, 0.1
Backlight OptionYes
Log Function TypeAutomatic, Manual
Measurement ModespH with mV and Temperature, Relative mV with mV and Temperature
Calibration Points1 to 5 (pH), 1 (Relative mV), 1 (Temperature)
Range (Relative m V)±2000 mV
Accuracy (Temperature)±0.3°C (±0.5°F)
Calibration Points (p H)USA: 2, 4.01, 7, 10.01, 12; NIST: 1.68, 4.01, 6.87, 9.18, 12.46; DIN: 1.09, 3.06, 4.65, 6.79, 9.23, 12.75; FSCI: 1, 3, 6, 8, 10, 13
Data Management DetailsPrinted or CSV Format
Resolution (Temperature)0.1°C (0.1°F)
Temperature CompensationAutomatic, Manual
Certifications/ComplianceCE, TUV 3-1, FCC Class A, Without NIST-traceable Calibration Certificate
Temperature Range (Metric)-5°C to +105°C
Temperature Range (English)23°F to 221°F
